Products   >  Laser lights   >  Galvo Scanner lasers  > Transformer 1W RGB 15KPPS ILDA Animation Laser Light
Product Name:
Transformer 1W RGB 15KPPS ILDA Animation Laser Light
:
:
:

Product Description:

Transformer 1W RGB:   1W Multi Color RGB  Animation laser (Red: 300mW, Green: 100mW, Blue: 700mW 450nm, blended white: 1000mW), 10kpps

Features:
*Housing: Lightweight, compact design, dust free, professional design, strong protected, NON-Interlock housing
*Animations: built-in 96 kinds of Geometric animations and 103 kinds of Cartoon Animations.
* LCD digital display for function setting
 (1) working mode: AUTO, Sound, DMX, Master/slave, Dimming.
 (2) graphics selection: (1) beam mixed: sheet, dircles, waves, boxes, points (2) cartoon mixed: KTV, Halloween, Christmas, Wedding, Animals.
 (3) Invert Mode Set
 (4) Lasers Type Set
 (5) Color Type Set
 (6) TTL or Analogue setting
 (7) Graphic Size Set
 (8) Scan Speed Set
 (9) Velocity Set
 (10) Sensitivity Set
*DMX mode: pattern selections, laser diode brightness adjustment for analogue modulation, color change, X/Y movement, dimmer, animations rotation, zoom in/out, drawing, etc.
* Play Mode Sound Active, AUTO-Beam, AUTO-Animation, DMX, Master/ Slave, PC Control
* Scanner: High-speed optical scanner
* Under AUTO/SOUND/DMX mode, beam angle was originally designed to split to very wide angle (about 60°) .
* Under PC laser software control, beam angle is the original scanner angle e.g., scanner 30° can only display max 30°,  scanner 60° can only display max 60°.
* DMX channel: 19
* AUTO change to PC mode once connected to laser software with computer via ILDA cable.
* Built-in microphone to detect the outside sound
* DB25 ILDA interface for computer use
* XRL interface for DMX or master/slave
* Key switch ON/OFF for compliance of laser light standard
* Power corn IN for main power source
* Power Supply Bi-Voltage 110V to 220V-250V, 50/60HZ, 20W
* Laser size: 21*21*11cm
* 1pc: N.W.: 2.2KG, G.W.: 3.1KG, V.W.: 3.6KG
* Inner box: 26.6*25.5*19CM,
* carton box: 54*28.5*42CM, 4pcs/CTN
