Products   >  Galvo Scanner lasers   >  Transformer 20W RGB SD ILDA PRO Laser light
Product Name:
Transformer 20W RGB SD ILDA PRO Laser light
:
:
:

Product Description:

Transformer 20W RGB SD:  20W RGB 35KPPS ILDA Animation disco laser Light.   (Red 5.5W 638nm+ Green 6W 520nm + Blue 8.5W 450nm, blended white: 20W)
scanner speed: 35kpps,35K big scanner mirror size X:9*11mm Y:9*18mm.
modulation: analogue

 ◆Feature: Animation laser with high-speed optical scanner to create animated graphics, 256 beam show and graphics show patterns, and with the function of unique blanking, frequently flashing, rotating, movement, billowing, zoom (+/-), drawing and speed etc. SD Card supports “.ild” format picture which shows customize animations. All functions are shown through LCD indicator. X and Y patterns can be adjusted separately. The scanning speed of the animations from SD card can be set manually. Animations in SD card can be selected and displayed permanently or replayed times.
* Compact housing with 3 floors design for dust free.
* LCD digital display for function setting
◆Scanner: High-speed optical scanner, big angle scanning (0 to 30°)
◆Play Mode (1) Laser: Sound Active, AUTO-Beam, AUTO-Animation, DMX512 (CH17), Master/ Slave (2) SD card (3) ILDA (4) remote control
* DMX channel: 17CH
* DB25 ILDA interface for computer use
* XRL interface for DMX or master/slave
* Remote interlock for compliance of laser light standard.
* Key switch ON/OFF for compliance of laser light standard
* Power corn IN for main power source
◆Power Supply: Bi-Voltage 110V to 220V-250V, 50/60HZ, 60W
*Net weight: 28kg
*Gross weight: 34kg
*Outer box size: 50*58*41cm (0.12cbm), 1PCS/CTN.
*Optional flightcase 17kgs

Package includes:
1) 1pcs laser light
2) 1pcs power cable
3) 1pcs 2GB SD card with handreds of ild. files and free laser software
4) 1pcs manual
