Products   >  Movinghead Lasers   >  LHA1WRGB DMX Animation Mini Movinghead Laser Light
Product Name:
LHA1WRGB DMX Animation Mini Movinghead Laser Light
:
:
:

Product Description:

LHA1WRGB: 1W RGB 15KPPS DMX mini moving-head animation laser light. (Red 300mW 638nm+ Green 100mW 525nm + Blue 600mW 450nm)
LHA2WRGB: 2W RGB 15KPPS DMX mini moving-head animation laser light. (Red 400mW 638nm+ Green 600mW 520nm + Blue 1W 450nm)

DMX Animation Mini Moving-Head laser Light
Feature:
* Smaller size, light weight, easy for installation
* Advanced mini moving head with high focusing laser to project logos, words, and animations.
* It has been pre-programmed with 103 kinds of geometric figures and 10 kinds of animations. All those patterns can be operated under DMX control, which has functions of moving up/down/left/right, zoom in/out, rotating, drawing, billowing, speed, color, animation selection, etc.
* The most advance function is the horizontal or vertical speed control, which has 256 levels on the speed.
*On the easy-to-use LCD indicator, this laser light can be set to the stay-still mode. Horizontal angle at 0 to 540°and vertical angle at 0 to 270°. Each level on horizontal angle is 2.1° and on vertical angle is 1.05°.
*On DMX mode, 2 animations in one frame can be operated separately.
*Scanner: High-speed optical scanner, big angle scanning (0 to 30°)
*Horizontal moving angle: 540°
*Vertical moving angle: 270°
*Scanning: Tilt and Pan
*2 units moving head laser lights are linked via XRL cable and can be operated in Mirror Symmetry mode.
*Virtual Operating platform: LCD802 indicator
*Play Mode: Sound Active, AUTO-Beam, AUTO-Animation, DMX, Master/ Slave,
*DMX channels: 19
*Safety Capacity Design according to security and good performance, safer to human and environment. Master/Slave mode and DMX512 mode will shut off laser automatically without trigger signal
*Power Supply: Bi-Voltage 110V to 220V-250V, 50/60HZ, 20W
*Item size: 180*140*270mm
*Net Weight: 3Kg
*Gross Weight: 3.5Kg (in carton box)
*Volume Weight: 4.4Kg (/5000) or 3.7Kg(/6000), with carton box
*Inner Box: 230*200*360mm (0.017CBM)
*Outer Box: 420*380*480mm (0.077CBM), 4pcs/carton
